Intumescent Fireproof Coating
VeryPaint® SP-9316 is a two-component epoxy intumescent fireproof coating featuring excellent film formation and strong adhesion, with 100% solid content and no solvent emissions.
When exposed to a 1200°C flame, the coating expands over 50 times its original thickness, providing outstanding high-temperature resistance and thermal insulation performance. It is a halogen-free, environmentally safe system compatible with epoxy zinc-rich primers and polyaspartic polyurea topcoats for enhanced corrosion and weather resistance.
- AVAILABILITY: IN Stock
- PRICE: $13.50
$16.00
Product Features
- Two-component epoxy coating system
- Dry film adhesion strength ≥3 MPa
- Halogen-free, environmentally friendly, solvent-free, 100% solids
- No exudation after 500 hours under high temperature and high humidity conditions (85°C × 85% RH)
- Under 1200°C flame exposure:
- Expansion ratio ≥50 times
- Temperature difference between front and back sides of the coating can exceed 800°C
- A 0.5 mm dry film provides ≥30 minutes effective thermal insulation protection (backside temperature ≤200°C)
- A 5.0 mm dry film provides ≥20 minutes effective thermal insulation protection (backside temperature ≤200°C)
- No softening or peeling after 48 hours water immersion
- Viscosity can be adjusted during application using dedicated epoxy thinner if required
- Compatible with epoxy zinc-rich primers and polyaspartic polyurea weather-resistant flame-retardant topcoats for enhanced corrosion resistance, weatherability, and fire protection performance
Typical Applications
- Onshore oil & gas industry
- Petrochemical facilities
- Power generation industry
- Fire protection of steel structures, pipelines, and vessels exposed to hydrocarbon fires
- Protection for new energy battery pack systems
- Industrial thermal insulation and passive fire protection systems
Technical Parameters
| Item | Standard | SP-9316 Specification |
|---|---|---|
| Appearance | Visual inspection | White viscous coating |
| Components | - | Two-component |
| Mixing Ratio | - | A:B (curing agent) = 6:1 by weight |
| Viscosity | cps | 50,000–100,000 |
| Solid Content | % | 100 |
| Environmental Compliance | RoHS | Halogen-free, Pass |
| Adhesion on Steel | Cross-cut test | Grade 0 |
| Recommended Dry Film Thickness | 0.5 h fire resistance | ≥0.5 mm |
| 2.0 h fire resistance | ≥3.0 mm | |
| Application Method | - | Heated two-component spraying equipment, modified airless spraying, trowel coating, scraper coating, or brush coating |
| Curing Condition | - | 23°C: Tack-free 4h, fully cured 24h |
| - | 80°C: Tack-free 2h, fully cured 8h |
Application Notes
At ambient temperatures below 20°C, the material may become highly viscous. It is recommended to add dedicated epoxy thinner to ensure good application performance and sprayability.
Fire Resistance Test
The following test evaluated SP-9316 applied at a dry film thickness of 0.5 mm on different substrates including mica board and aluminum alloy plate.
- Uncoated steel plates exceeded 600°C within approximately 3 minutes under flame exposure. This temperature reaches the phase transition point of low-carbon steel, significantly reducing its structural strength and load-bearing capacity.
- In contrast, substrates coated with SP-9316 maintained backside temperatures below 200°C within 30 minutes of flame exposure. This substantially improves operational safety and passive fire protection performance.
